Model
DSC-803M three axis
display for Mills
with connector adapters
(3)
$395.00
Scales are not included in
the above price.
Display
Detail:
Display: Green F.N.D
7 digits with "-" sign
Operation temperature:
-5℃ ~ 45℃
Voltage consumption:
15VA
Power source: AC 50 ~
265V, 50/60Hz (free
voltage)
Key pad: Membrane
Type
Function Display:
RED
LED
Here are the features that
are available in the
display:
Bolt Hole Calculation
Preset for each axis
Reset for each axis
1/2 divide for finding
the centerline
Inch/millimeter conversion
Reference mark
add/subtract function
absolute/incremental
positioning
Data memory: 50 positions
per axis
Memory back up
Radius/Diameter Switchable
Green L.E.D.s
Die cast housing
Resolution:
10um/.0005" (Fits Sargon,
Acu-rite, Anilam and Quality
Measurement Systems scales)
5um/.0002"
1um/.00005"
The display also includes
the following:
-
manual
-
display cover
-
2 or 3 adapters
